| Screen Size | 17" |
| CPU | Intel® Celeron® M 575 2.0GHz Intel® Core™ 2 Duo P8400 2.26GHz Intel® Core™ 2 Duo T9400 2.53GHz |
| Max RAM | 4 GB |
| RS232 | 1 |
| RS232/422/485 | 1 |
| LAN | 2 |
| Max Resolution | 1280 x 1024 |
| RAM type | 2 x 200-pins DDR2 SO-DIMM |
| Chipset | Intel® GM45 + ICH9M |
| Brightness | 300 |
| Contrast Ratio | 800:1 |
| LCD Color | 16.7M |
| Pixel Pitch (mm) | 0.264(H) x 0.264(V) |
| Viewing Angle (H/V) | 160º/160º |
| Backlight MTBF (hrs) | 50000 |
| USB | 6 |
| Power Switch | 1 |
| Reset button | 1 |
| VGA | 1 |
| Power Jack | 1 |
| Audio | 1 |
| HDMI | 1 |
| HDD | 1 x 2.5” SATA HDD bay |
| SSD | CF Type II |
| CD-ROM | 1 x slim type ODD bay |
| WiFi | IEEE 802.11 b/g/n (internal PCIe mini card) |
| Bluetooth | Bluetooth V2.0 (internal USB) |
| Optional HSUPA Modem | Optional (internal USB) |
| Camera Module | 300K pixels |
| Microphone | yes |
| Dimensions (WxHxD) (mm) | 410 x 349 x 83 |
| Net Gross Weight | 6.2 Kg |
| System Cooling | Active with fan |
| Operation Temperature | 0°C~40°C with SATA HDD -10°C~50°C with CF card or SATA SSD |
| Storage Temperature | -20°C~60°C |
| Construction | ABS + PC Plastic front frame |
| Mounting | Panel, Wall, Rack, Stand and Arm VESA 100mm x 100mm |
| IP Level | Front Frame IP64 |
| Power Requirement | 12 VDC |
| Power Consumption | 90 W |
