Specification
CPU Intel Atom N270 1.6G
Chipset NB: 945GSE
SB: ICH7M
Memory DDR2 800, Max. 2GB
Touch-screen 12” , 800x600,400 nits, 5Wire resistive
External I/O USB 2.0 x 2
COM x 2(RS232/422/485 x 1, RS232 x 1)
Giga LAN x 1
PS/2 x 1
DC-In x 1
Storage HDD 2.5''SATA HDD drive bay x 1 ,320G
CF Card slot x 1
DOM x 1(44PIN 180D,PCI card and DOM can't be in machine at the same time)
Expansion Mini-PCIe x 1
PCIe x 1
Regulations FCC-A, CE (EMC), VCCI, UL/cUL
Size Panel mount: 350×295×83.2mm
Weight 7.2 Kg
ordering information WTP-8865-12/Intel N270 1.6G/512M RAM/320GB HDD/Resistive Low reflection Sunlight readable
0~40° C operation temp
WTP-8865-12/Intel N270 1.6G/512M RAM/320GB HDD/Resistive/0~40° C operation temp
WTP-8865-12 Intel N270 1.6G/512M RAM/80GB HDD/Resistive/0~55° C operation temp/with fan
WTP-8865-12/Intel N270 1.6G/512M RAM/80GB HDD/Resistive Low reflection Sunlight readable
|
